ZCHENG FUEL DISPENSER
ZC-Series -
MODEL ZC-11122
PRODUT 1
220V MOTOR 1PCs
GEAR PUMP 1PCs
FLOW METER 2PCs
NOZZLE 11A 2PCs
CONTROLLER ZC-B 1PCs
OTHER SPECIFICATION
AMBIENT TEMPERATURE -250C to 550C
FLOW RATE 5-60L/min or 5-90L/min
SUNCTION DISTANCE 6m (Vertical) and 50m (Horizontal)
POWER 1HP (0.75kw)
UINT PRICE RANGE 0.01-999.9,
SINGLE VOLUME RANGE 0.01-999999.99
ACCUMULATIVE VOLUME RANGE 0.01-9999999999.99
INLET & OUTLET PRESSURE ≥54kPa & ≤0.3MPa
ZCHENG SPARE PART
MAINBOARD ZC-B-01
DISPLAY, KEYPAD, POWR BOARD, PULSER-ZCPS-600, SOLENOID VALVE ZCMSF-20A, HOSE WITH SWIVEL ¾’’ 3m BSPF, NOZZLE zcn-11 (Inlet: ¾’’ BSPF, SPOUT: 13/16’’), MOTOR ZCMT-220V, TOKHEIM PUMP ZCP-TK2, TOKHEIM METER ZCP-TK3
